- Size: 5500*4000*3100
- Place of Origin: Tengzhou, China
- Brand Name: Tengzhou Forging Press Machine Tool NO2 Works
- Model Number: YTD-5000T
- Weight: 190000.000 kg
This series of hydraulic press is a universal pressing device, which is suitable for the pressing process of plastic materials. Products such as powder molding, plastic molding, cold (hot) extrusion metal forming, stamping, bending and stretching sheet joint, flanging and correction process.
In addition to the above functions, the cylinder is also provided with the top out, time delay, automatic return and other functions.
- Size: 5500*4000*3100
- Place of Origin: Tengzhou, China
- Brand Name: Tengzhou Forging Press Machine Tool NO2 Works
- Model Number: YTD-5000T
- Weight: 190000.000 kg
型号Type | 5000T | ||
主缸公称力Nominal pressure | KN | 8400*6 | |
液体工作压力Max liquid pressure | Mpa | 25.5 | |
主缸行程Slide stroke | mm | 800 | |
最大开口高度daylight | mm | 1900 | |
有效工作台尺寸（左右*前后）table size | mm | 3900*2400 | |
滑块速度 Slide speed | 空程下行Rapid downward | mm/s | 80-100 |
慢速加压Press | 8-12 | ||
回程Return | 60-80 | ||
电机功率motor power | KW | 187.5 | |
